🚀🚀🚀This is an AI high-performance reasoning C++ library, Currently supports the deployment of yolov5, yolov7, yolov7-pose, yolov8, yolov8-seg, yolov8-pose, yolov8-obb, yolox, RTDETR, DETR, depth-anything, yolop, yolopv2, SMOKE, yolov9 and other models.🚀🚀🚀

Stars: 87

Visit
 screenshot

This project is a c++ version of the AI reasoning library that supports the reasoning of tensorrt models. It provides accelerated deployment cases of deep learning CV popular models and supports dynamic-batch image processing, inference, decode, and NMS. The project has been updated with various models and provides tutorials for model exports. It also includes a producer-consumer inference model for specific tasks. The project directory includes implementations for model inference applications, backend reasoning classes, post-processing, pre-processing, and target detection and tracking. Speed tests have been conducted on various models, and onnx downloads are available for different models.

README:

dl_model_infer

Language Language Language Language Language

Introduce

This project is modified based on the AIInfer, Tanks for this project.

This is a c++ version of the AI reasoning library. Currently, it only supports the reasoning of the tensorrt model. The follow-up plan supports the c++ reasoning of frameworks such as Openvino, NCNN, and MNN. There are two versions for pre- and post-processing, c++ version and cuda version. It is recommended to use the cuda version., This repository provides accelerated deployment cases of deep learning CV popular models, and cuda c supports dynamic-batch image process, infer, decode, NMS.

Update

  • 2023.05.27 update yolov5、yolov7、yolov8、yolox
  • 2023.05.28 update rt_detr
  • 2023.06.01 update yolov8_seg、yolov8_pose
  • 2023.06.09 update yolov7_cutoff
  • 2023.06.14 update yolov7-pose
  • 2023.06.15 Adding Producer-Consumer Inference Model for yolov8-det
  • 2023.06.24 update 3D objection detection algorithm smoke
  • 2023.09.06 update deploy for detr in mmdetection
  • 2024.01.26 update yolov8-obb
  • 2024.02.06 update depth-anything
  • 2024.02.12 update yolop & yolopv2
  • 2024.02.26 update yolov9

Environment

The following environments have been tested:

  • ubuntu16.04
  • cuda11.1
  • cudnn8.6.0
  • TensorRT-8.5.1.7
  • gcc5.4.0
  • cmake-3.24.0
  • opencv-4.5.5
  • Eigen3
  • yaml

You can also use docker, How to use it is as follows:

docker pull longxiaowyh/dl_model_infer:v1.0
nvidia-docker run -itu root:root --name dl_model_infer --gpus all -v /your_path:/target_path -v /tmp/.X11-unix/:/tmp/.X11-unix/ -e DISPLAY=unix$DISPLAY -e GDK_SCALE -e GDK_DPI_SCALE  -e NVIDIA_VISIBLE_DEVICES=all -e NVIDIA_DRIVER_CAPABILITIES=compute,utility --shm-size=64g longxiaowyh/dl_model_infer:v1.0 /bin/bash

Model Export Tutorial

Use of CPM (wrapping the inference as producer-consumer)

  • cpm.hpp Producer-consumer model
    • For direct inference tasks, cpm.hpp can be turned into an automatic multi-batch producer-consumer model
cpm::Instance<BoxArray, Image, yolov8_detector> cpmi;
auto result_futures = cpmi.commits(yoloimages);
for (int ib = 0; ib < result_futures.size(); ++ib)
{
    auto objs = result_futures[ib].get();
    auto image = images[ib].clone();
    for (auto& obj : objs)
    {
        process....
    }
}

Quick Start

Take yolov8 target detection as an example,modify CMakeLists.txt and run the command below:

git clone [email protected]:yhwang-hub/dl_model_infer.git
cd dl_model_infer
mkdir build && cd build
cmake .. && make
cd ../workspaces
./infer -f yolov8n.transd.trt -i res/dog.jpg -b 10 -c 10 -o cuda_res -t yolov8_det

You can also use a script to execute,The above instructions are written in the compile_and_run.sh script,for example:

rm -rf build && mkdir -p build && cd build && cmake ..  && make -j9 && cd ..
# mkdir -p build && cd build && cmake ..  && make -j48 && cd ..
cd workspaces

rm -rf cuda_res/*

# ./infer -f yolov8n.transd.trt -i res/dog.jpg -b 10 -c 10 -o cuda_res -t yolov8_det

cd ..

Then execute the following command to run

cd dl_model_infer
bash compile_and_run.sh

Project directory introduction

AiInfer
   |--application # Implementation of model inference application, your own model inference can be implemented in this directory
     |--yolov8_det_app # Example: A yolov8 detection implemented
     |--xxxx
   |--utils # tools directory
     |--backend # here implements the reasoning class of backend
     |--common # There are some commonly used tools in it
       |--arg_parsing.h # Command line parsing class, similar to python's argparse
       |--cuda_utils.h # There are some common tool functions of cuda in it
       |--cv_cpp_utils.h # There are some cv-related utility functions in it
       |--memory.h # Tools related to cpu and gpu memory application and release
       |--model_info.h # Commonly used parameter definitions for pre- and post-processing of the model, such as mean variance, nms threshold, etc.
       |--utils.h # Commonly used tool functions in cpp, timing, mkdir, etc.
       |--cpm.h # Producer-Consumer Inference Model
     |--post_process # Post-processing implementation directory, cuda post-processing acceleration, if you have custom post-processing, you can also write it here
     |--pre_process # pre-processing implementation directory, cuda pre-processing acceleration, if you have custom pre-processing can also be written here
     |--tracker # This is the implementation of the target detection and tracking library, which has been decoupled and can be deleted directly if you don’t want to use it
   |--workspaces # Working directory, where you can put some test pictures/videos, models, and then directly use the relative path in main.cpp
   |--mains # This is the collection of main.cpp, where each app corresponds to a main file, which is easy to understand, and it is too redundant to write together
   |--main.cpp # Project entry

Speed Test

Tested on Jetson Orin, the test includes the entire process (image preprocessing + model inference + post-processing decoding)、

Model Precision Resolution FPS(bs=1)
rtdetr_r50 FP16 640x640 19
yolov8n FP16 640x640 126
yolov8n-seg FP16 640x640 92
yolov8s-pose FP16 640x640 58
yolov8s-obb FP16 1024x1024 38
yolov5s FP16 640x640 92
yolov7 FP16 640x640 34
yolov7_cutoff FP16 640x640 32
yolov7-w6-pose FP16 960x960 22
yolox_s FP16 640x640 91
detr FP16 800x1190 18
depth_anything_vits14 FP16 518x518 19
yolop FP16 640x640 40
yolopv2 FP16 480x640 26

onnx downloads

model baiduyun
yolov5 链接: https://pan.baidu.com/s/1Bwwo8--JS8Vkw6METz2dIw 提取码: 47ax
yolov7 链接: https://pan.baidu.com/s/1gb0W177xhnrseJF6CfdMEA 提取码: rvg5
yolov7_cutoff 链接: https://pan.baidu.com/s/16bKgt_DWNmk26q-utLyCfA 提取码: q7kf
yolov8 链接: https://pan.baidu.com/s/18Cm-tN21cus3XyirqLE_eg 提取码: j8br
yolov8-seg 链接: https://pan.baidu.com/s/1s2Gp_Jedhi9-p_Z2utJV-Q 提取码: wr5t
yolov8-pose 链接: https://pan.baidu.com/s/1lP8kiKu2a6h_FAZSSkhUgg 提取码: 7p6a
yolox 链接: https://pan.baidu.com/s/1U0gzW_YMbvNMtKzo4_cluA 提取码: 4xct
rt-detr 链接: https://pan.baidu.com/s/1Ft0-ewuCTK2BxTS1q1Vdtw 提取码: ekms
yolov7-pose 链接: https://pan.baidu.com/s/1uI6u5oKDrnroluQufIWF7w 提取码: ed9r
DETR 链接: https://pan.baidu.com/s/1_PQVPKy0QiFWJaB7HhyTSg 提取码: j7fs
yolov8-obb 链接: https://pan.baidu.com/s/1bMZuZPtTNjo5tl5heOdJRw 提取码: fudj
Depth-Anything 链接: https://pan.baidu.com/s/1ZiE1AVvpB6owND5wEqHwMw 提取码: cp97
YOLOP 链接: https://pan.baidu.com/s/1Q0itb-TMoYpx27x0stwUag 提取码: rc3p
YOLOPV2 链接: https://pan.baidu.com/s/19sNBrwIx2TAD7iOJtZrDuA 提取码: 15vm
YOLOV9 链接: https://pan.baidu.com/s/1Cotnig9BgeJt7gAW-Vy8Pg 提取码: n4hm

Reference

Thanks for the following items
